100ml-1000ml PET Bottle Water Filling Machine Stainless Steel
The water filling machine adopts bottle neck holding transmission technology to realize fully automatic rinsing, filling and capping.
The application of alarm devices for bottle jam, bottle shortage, bottle damage, cap shortage, overloading ect. In several places ensure the quality of its production. The water bottle filling machine obtains advantages of high reliability, high efficiency, high grade of automation and easy operation, etc.
PET Water Bottle Filling Machine Features:
1. The suspending bottle-necks cramping design makes the whole production line more stable during the working process and it also avoids malfunctions caused by the differences of thickness and height of the bottle. This design also dramatically reduces the required number of changeable parts, makes it more convenient to change the different size bottles.
2. The water filling machine uses advanced technology from Germany and Italy. Isobaric filling technology is used in this machine. Filling quickly and the amount of the liquid can be controlled accurately. Also the beverage-holding tank is fully closed and the CIP interface is installed.
3. Magnetic torque is used for screw capping, and the power of screw capping can be adjusted freely. It can use a constant power screw the plastic caps and will not damage the caps.
Water Bottle Filling Machine Data:
| Model | GG-GT4T-4G |
| Voltage | 220V 50/60Hz |
| Air Pressure | 0.5-0.7Mpa |
| SS Material | SUS304 |
| Pistion Material | PTFE |
| Main Cylinder | SMC(Japan) |
| PLC&Screen | Delta |
| Filling Volume Range | 100-1000ml |
| Filling Heads | 4 |
| Filling Speed | 16-20 Bottles/Min |
| Machine Size (L*W* H) | 2000*1050*1900 mm |
| Weight | 350Kg
|
